KaliVeda
Toolkit for HIC analysis
|
#include <KVDataAnalysisLauncher.h>
Private Types | |
enum | ElementId { CB_DataRepository , CB_AnalysisTask , CB_DataSet , CB_System , CB_Trigger , LB_Runs , B_Libs , B_Incs , B_Process , B_Quit } |
Private Member Functions | |
void | BuildResourceName (const Char_t *name, TString &, TString &) |
void | DisableUserClassList () |
Remove all entries from user class combo box & disable text entry. More... | |
void | EnableUserClassList () |
void | FillListOfUserClasses () |
void | GenerateNewUserClass () |
KVDataSetAnalyser * | GetDataAnalyser (KVDataAnalysisTask *task=0) |
const Char_t * | GetResource (const Char_t *name, const Char_t *defaultvalue="") |
const Char_t * | GetSavedResource (const Char_t *name, const Char_t *defaultvalue="") |
const Char_t * | GetUserClass () |
Returns currently selected user class name. More... | |
void | SetResource (const Char_t *name, const Char_t *value) |
void | SetUserClass (const Char_t *) |
void | SetUserClassList () |
Sets the list of all available user classes in the drop down list. More... | |
TString | SystemBatchName () |
Get the system name for the batch name. More... | |
Additional Inherited Members | |
![]() | |
enum | EEditMode |
enum | EStatusBits |
![]() | |
enum | EDeprecatedStatusBits |
enum | EStatusBits |
![]() | |
static TClass * | Class () |
static const char * | Class_Name () |
static constexpr Version_t | Class_Version () |
static const char * | DeclFileName () |
![]() | |
static TClass * | Class () |
static const char * | Class_Name () |
static constexpr Version_t | Class_Version () |
static const char * | DeclFileName () |
![]() | |
static TClass * | Class () |
static const char * | Class_Name () |
static constexpr Version_t | Class_Version () |
static const char * | DeclFileName () |
static const TGGC & | GetBckgndGC () |
static const TGGC & | GetBlackGC () |
static Pixel_t | GetBlackPixel () |
static Pixel_t | GetDefaultFrameBackground () |
static Pixel_t | GetDefaultSelectedBackground () |
static const TGGC & | GetHilightGC () |
static const TGGC & | GetShadowGC () |
static const TGGC & | GetWhiteGC () |
static Pixel_t | GetWhitePixel () |
![]() | |
static TClass * | Class () |
static const char * | Class_Name () |
static constexpr Version_t | Class_Version () |
static const char * | DeclFileName () |
static Int_t | GetCounter () |
![]() | |
static TClass * | Class () |
static const char * | Class_Name () |
static constexpr Version_t | Class_Version () |
static const char * | DeclFileName () |
![]() | |
static TClass * | Class () |
static const char * | Class_Name () |
static constexpr Version_t | Class_Version () |
static const char * | DeclFileName () |
static Longptr_t | GetDtorOnly () |
static Bool_t | GetObjectStat () |
static void | SetDtorOnly (void *obj) |
static void | SetObjectStat (Bool_t stat) |
![]() | |
static Bool_t | AreAllSignalsBlocked () |
static Bool_t | BlockAllSignals (Bool_t b) |
static TClass * | Class () |
static const char * | Class_Name () |
static constexpr Version_t | Class_Version () |
static Bool_t | Connect (const char *sender_class, const char *signal, const char *receiver_class, void *receiver, const char *slot) |
static Bool_t | Connect (TQObject *sender, const char *signal, const char *receiver_class, void *receiver, const char *slot) |
static const char * | DeclFileName () |
static Bool_t | Disconnect (const char *class_name, const char *signal, void *receiver=nullptr, const char *slot=nullptr) |
static Bool_t | Disconnect (TQObject *sender, const char *signal=nullptr, void *receiver=nullptr, const char *slot=nullptr) |
![]() | |
kEditDisable | |
kEditDisableBtnEnable | |
kEditDisableEvents | |
kEditDisableGrab | |
kEditDisableHeight | |
kEditDisableKeyEnable | |
kEditDisableLayout | |
kEditDisableResize | |
kEditDisableWidth | |
kEditEnable | |
kIsHtmlView | |
![]() | |
kBitMask | |
kCanDelete | |
kCannotPick | |
kHasUUID | |
kInconsistent | |
kInvalidObject | |
kIsOnHeap | |
kIsReferenced | |
kMustCleanup | |
kNoContextMenu | |
kNotDeleted | |
kObjInCanvas | |
kOverwrite | |
kSingleKey | |
kWriteDelete | |
kZombie | |
![]() | |
TString | GetMWMfuncString () const |
TString | GetMWMinpString () const |
TString | GetMWMvalueString () const |
![]() | |
void | DoRedraw () override |
virtual void | Draw3dRectangle (UInt_t type, Int_t x, Int_t y, UInt_t w, UInt_t h) |
TString | GetOptionString () const |
const TGResourcePool * | GetResourcePool () const |
void * | GetSender () override |
virtual void | StartGuiBuilding (Bool_t on=kTRUE) |
![]() | |
TGWindow (const TGWindow &tgw) | |
TGWindow (Window_t id) | |
TGWindow & | operator= (const TGWindow &tgw) |
![]() | |
TGObject & | operator= (const TGObject &tgo) |
![]() | |
virtual void | DoError (int level, const char *location, const char *fmt, va_list va) const |
void | MakeZombie () |
![]() | |
virtual const char * | GetSenderClassName () const |
![]() | |
static Time_t | GetLastClick () |
![]() | |
static Int_t | CheckConnectArgs (TQObject *sender, TClass *sender_class, const char *signal, TClass *receiver_class, const char *slot) |
static TString | CompressName (const char *method_name) |
static Bool_t | ConnectToClass (const char *sender_class, const char *signal, TClass *receiver_class, void *receiver, const char *slot) |
static Bool_t | ConnectToClass (TQObject *sender, const char *signal, TClass *receiver_class, void *receiver, const char *slot) |
![]() | |
TList * | fBindList |
TString | fClassName |
Atom_t * | fDNDTypeList |
TString | fIconName |
TString | fIconPixmap |
UInt_t | fMWMFuncs |
UInt_t | fMWMInput |
UInt_t | fMWMValue |
TString | fResourceName |
TString | fWindowName |
UInt_t | fWMHeight |
UInt_t | fWMHeightInc |
EInitialState | fWMInitState |
UInt_t | fWMMaxHeight |
UInt_t | fWMMaxWidth |
UInt_t | fWMMinHeight |
UInt_t | fWMMinWidth |
UInt_t | fWMWidth |
UInt_t | fWMWidthInc |
Int_t | fWMX |
Int_t | fWMY |
kDontCallClose | |
![]() | |
Bool_t | fLayoutBroken |
TGLayoutManager * | fLayoutManager |
TList * | fList |
Bool_t | fMapSubwindows |
Int_t | fMustCleanup |
![]() | |
Pixel_t | fBackground |
Int_t | fBorderWidth |
Int_t | fDNDState |
UInt_t | fEventMask |
TGFrameElement * | fFE |
UInt_t | fHeight |
UInt_t | fMaxHeight |
UInt_t | fMaxWidth |
UInt_t | fMinHeight |
UInt_t | fMinWidth |
UInt_t | fOptions |
UInt_t | fWidth |
Int_t | fX |
Int_t | fY |
kDeleteWindowCalled | |
![]() | |
UInt_t | fEditDisabled |
TString | fName |
Bool_t | fNeedRedraw |
const TGWindow * | fParent |
![]() | |
TGClient * | fClient |
Handle_t | fId |
![]() | |
kOnlyPrepStep | |
![]() | |
TList * | fListOfConnections |
TList * | fListOfSignals |
Bool_t | fSignalsBlocked |
![]() | |
static TGLayoutHints * | fgDefaultHints |
![]() | |
static const TGGC * | fgBckgndGC |
static const TGGC * | fgBlackGC |
static Pixel_t | fgBlackPixel |
static Window_t | fgDbw |
static Int_t | fgDbx |
static Int_t | fgDby |
static Pixel_t | fgDefaultFrameBackground |
static Pixel_t | fgDefaultSelectedBackground |
static const TGGC * | fgHilightGC |
static Bool_t | fgInit |
static UInt_t | fgLastButton |
static Time_t | fgLastClick |
static const TGGC * | fgShadowGC |
static UInt_t | fgUserColor |
static const TGGC * | fgWhiteGC |
static Pixel_t | fgWhitePixel |
![]() | |
static Int_t | fgCounter |
![]() | |
static Bool_t | fgAllSignalsBlocked |
|
private |
Enumerator | |
---|---|
CB_DataRepository | |
CB_AnalysisTask | |
CB_DataSet | |
CB_System | |
CB_Trigger | |
LB_Runs | |
B_Libs | |
B_Incs | |
B_Process | |
B_Quit |
Definition at line 105 of file KVDataAnalysisLauncher.h.
KVDataAnalysisLauncher::KVDataAnalysisLauncher | ( | const TGWindow * | p = 0 , |
UInt_t | w = 200 , |
||
UInt_t | h = 400 |
||
) |
Main window width and height can be set using .kvrootrc variables: KaliVedaGUI.MainGUIWidth: 800 KaliVedaGUI.MainGUIHeight: 600 Maximum column width of runlist can be set using: KaliVedaGUI.MaxColWidth: 500
Definition at line 436 of file KVDataAnalysisLauncher.cpp.
KVDataAnalysisLauncher::~KVDataAnalysisLauncher | ( | ) |
Destructeur.
Definition at line 757 of file KVDataAnalysisLauncher.cpp.
|
private |
Build the full resource names for storing DataSet, Task, etc.
We store the current state of the interface using the following resource names:
"name" "cur_res" Repository KVDataAnalysisLauncher.Repository DataSet KVDataAnalysisLauncher.DataSet Task KVDataAnalysisLauncher.Task System KVDataAnalysisLauncher.System Trigger KVDataAnalysisLauncher.Trigger RunsList KVDataAnalysisLauncher.RunsList UserClass KVDataAnalysisLauncher.UserClass UserClassOptions KVDataAnalysisLauncher.UserClassOptions KVDataSelector KVDataAnalysisLauncher.KVDataSelector NbEventsToRead KVDataAnalysisLauncher.NbEventsToRead
We also keep a "memory" of all selected configurations using the following resource names:
"name" "saved_res" DataSet KVDataAnalysisLauncher.DataSet.[repository] Task KVDataAnalysisLauncher.Task.[repository].[dataset] System KVDataAnalysisLauncher.System.[repository].[dataset].[task] Trigger KVDataAnalysisLauncher.Trigger.[repository].[dataset].[task].[system] RunsList KVDataAnalysisLauncher.RunsList.[repository].[dataset].[task].[system].[trigger] UserClass KVDataAnalysisLauncher.UserClass.[repository].[dataset].[task].[system].[trigger] UserClassOptions KVDataAnalysisLauncher.UserClassOptions.[repository].[dataset].[task].[system].[trigger].[class] KVDataSelector KVDataAnalysisLauncher.KVDataSelector.[repository].[dataset].[task].[system].[trigger] NbEventsToRead KVDataAnalysisLauncher.NbEventsToRead.[repository].[dataset].[task].[system].[trigger]
N.B. [task]: it is the NAME of the task which is used in the resource name. N.B.2. [system]: it is the name given by SystemBatchName() which is used in the resource name. N.B.3. [trigger]: for the resource name we take "M > 4", "M>=8" "All" etc. and replace all ' ', '>' or '=' by '' to give "M4", "M8", "All", etc.
If name = "Repository", saved_res="" as we do not save it. If the resource cannot be saved because one of the resources that is needed to form the full resource name has not been set, saved_res="". Resource name for current value
Definition at line 1733 of file KVDataAnalysisLauncher.cpp.
void KVDataAnalysisLauncher::ClearListOfSelectedRuns | ( | ) |
Empty displayed list of selected runs.
Definition at line 2175 of file KVDataAnalysisLauncher.cpp.
Deselect all runs currently in the displayed list of runs.
Definition at line 1056 of file KVDataAnalysisLauncher.cpp.
|
private |
Remove all entries from user class combo box & disable text entry.
Definition at line 2056 of file KVDataAnalysisLauncher.cpp.
void KVDataAnalysisLauncher::EditUserClassFiles | ( | ) |
If environment variable $EDITOR is set, and if the currently selected user class has available source files, we open them in the user's favourite editor
Definition at line 2098 of file KVDataAnalysisLauncher.cpp.
|
private |
Reenable user class combo box & text entry, fill list with all known user classes & select the one corresponding to the current environment
Definition at line 2078 of file KVDataAnalysisLauncher.cpp.
Called when user presses "Runlist" button. Open dialogue box in which a runlist can be entered. The runs in the runlist will be selected.
Definition at line 2121 of file KVDataAnalysisLauncher.cpp.
Definition at line 176 of file KVDataAnalysisLauncher.h.
|
private |
Look at files in working directory & deduce list of user analysis classes. We look for any file ending in '.h'. If we can find a corresponding '.cpp' or '.C' or '.cxx', we consider that it is a user analysis class. This list is used to fill the "User Class" drop-down list. We add "[NEW]" at the end of the list: if selected, this will generate a new user analysis class for the currently selected data & analysis task
Definition at line 1853 of file KVDataAnalysisLauncher.cpp.
|
private |
called when user selects [NEW] in user class list we generate a new analysis class for currently selected data & task the source files are opened in the $EDITOR the new class is selected for the analysis Get name of new class
Definition at line 1961 of file KVDataAnalysisLauncher.cpp.
|
private |
Get analyser for task If task = 0 we return the current analyser
Definition at line 883 of file KVDataAnalysisLauncher.cpp.
Definition at line 1194 of file KVDataAnalysisLauncher.cpp.
Definition at line 1180 of file KVDataAnalysisLauncher.cpp.
|
private |
Handles resource file ".KVDataAnalysisGUIrc"
We return the current value of the resource "name"
Definition at line 1618 of file KVDataAnalysisLauncher.cpp.
Definition at line 1237 of file KVDataAnalysisLauncher.cpp.
|
private |
Handles resource file ".KVDataAnalysisGUIrc"
We look for a stored value of the resource "name" corresponding to the current values of all the resources which come before "name" in the list : Repository DataSet Task System Trigger These values are stored in resources with names like: KVDataAnalysisLauncher.[name].[repository].[dataset]...
If no stored value is found, the defaultvalue is returned
Definition at line 1647 of file KVDataAnalysisLauncher.cpp.
Definition at line 1222 of file KVDataAnalysisLauncher.cpp.
Definition at line 1208 of file KVDataAnalysisLauncher.cpp.
|
private |
Returns currently selected user class name.
Definition at line 2038 of file KVDataAnalysisLauncher.cpp.
Definition at line 206 of file KVDataAnalysisLauncher.h.
Run the analysis task.
Definition at line 1068 of file KVDataAnalysisLauncher.cpp.
Select all runs currently in the displayed list of runs.
Definition at line 1044 of file KVDataAnalysisLauncher.cpp.
void KVDataAnalysisLauncher::SetBatch | ( | ) |
Set the resource KVDataAnalysisLauncher.Batch according to whether button 'Batch' is down or up
Definition at line 1392 of file KVDataAnalysisLauncher.cpp.
Bool_t KVDataAnalysisLauncher::SetBatchParameters | ( | ) |
Open dialog to set batch parameters for job returns kFALSE if cancel is pressed
Definition at line 1410 of file KVDataAnalysisLauncher.cpp.
Definition at line 1267 of file KVDataAnalysisLauncher.cpp.
Sets the list of all available data sets in the data sets combo box.
Definition at line 797 of file KVDataAnalysisLauncher.cpp.
Definition at line 1246 of file KVDataAnalysisLauncher.cpp.
Sets the list of all possible repositories in the repository combo box.
Definition at line 771 of file KVDataAnalysisLauncher.cpp.
Handles resource file ".KVDataAnalysisGUIrc" We store the current state of the interface using the following resource names:
Repository KVDataAnalysisLauncher.Repository DataSet KVDataAnalysisLauncher.DataSet Task KVDataAnalysisLauncher.Task System KVDataAnalysisLauncher.System Trigger KVDataAnalysisLauncher.Trigger RunsList KVDataAnalysisLauncher.RunsList UserClass KVDataAnalysisLauncher.UserClass KVDataSelector KVDataAnalysisLauncher.KVDataSelector NbEventsToRead KVDataAnalysisLauncher.NbEventsToRead
We also keep a "memory" of all selected configurations using the following resource names:
DataSet KVDataAnalysisLauncher.DataSet.[repository] Task KVDataAnalysisLauncher.Task.[repository].[dataset] System KVDataAnalysisLauncher.System.[repository].[dataset].[task] Trigger KVDataAnalysisLauncher.Trigger.[repository].[dataset].[task].[system] RunsList KVDataAnalysisLauncher.RunsList.[repository].[dataset].[task].[system].[trigger] UserClass KVDataAnalysisLauncher.UserClass.[repository].[dataset].[task].[system].[trigger] KVDataSelector KVDataAnalysisLauncher.KVDataSelector.[repository].[dataset].[task].[system].[trigger] NbEventsToRead KVDataAnalysisLauncher.NbEventsToRead.[repository].[dataset].[task].[system].[trigger]
N.B. [task]: it is the NAME of the task which is used in the resource name. N.B.2. [system]: it is the name given by SystemBatchName() which is used in the resource name. N.B.3. [trigger]: for the resource name we take "M > 4", "M>=8" "All" etc. and replace all ' ', '>' or '=' by '' to give "M4", "M8", "All", etc.
Definition at line 1565 of file KVDataAnalysisLauncher.cpp.
Definition at line 1369 of file KVDataAnalysisLauncher.cpp.
void KVDataAnalysisLauncher::SetRunsList | ( | ) |
Sets the list of all available runs in the runs list box.
Definition at line 975 of file KVDataAnalysisLauncher.cpp.
Definition at line 1335 of file KVDataAnalysisLauncher.cpp.
Sets the list of all possible systems in the system list. Called every time a task is selected.
The choice of task may lead to a change of batch system:
Definition at line 912 of file KVDataAnalysisLauncher.cpp.
Definition at line 1301 of file KVDataAnalysisLauncher.cpp.
Sets the list of all possible tasks in the tasks combo box Called when a new dataset is selected in the dropdown list
Definition at line 835 of file KVDataAnalysisLauncher.cpp.
Sets selected user class in combo box according to e.g. a previously stored resource value. We update the resource corresponding to the current state of the interface. look for user class in list
Definition at line 1999 of file KVDataAnalysisLauncher.cpp.
|
private |
Sets the list of all available user classes in the drop down list.
Definition at line 1901 of file KVDataAnalysisLauncher.cpp.
Set the User's includes.
Definition at line 1453 of file KVDataAnalysisLauncher.cpp.
Set the User's libraries.
Definition at line 1437 of file KVDataAnalysisLauncher.cpp.
Get the system name for the batch name.
Definition at line 1680 of file KVDataAnalysisLauncher.cpp.
void KVDataAnalysisLauncher::SystemSelectionChanged | ( | ) |
Definition at line 1356 of file KVDataAnalysisLauncher.cpp.
void KVDataAnalysisLauncher::UpdateListOfSelectedRuns | ( | ) |
Called when the selected runs in TGListView lvRuns change. We update the run_index_list listOfRuns according to the current selection we modify the limits of the 'runs per job' widget
Definition at line 2144 of file KVDataAnalysisLauncher.cpp.
void KVDataAnalysisLauncher::UserClassSelected | ( | char * | class_name | ) |
Called when a user class is selected in the combo box. Updates batch name if 'auto batch name' is selected.
Definition at line 1929 of file KVDataAnalysisLauncher.cpp.
Bool_t KVDataAnalysisLauncher::WarningBox | ( | const char * | title = "Warning" , |
const char * | msg = "Warning" , |
||
Bool_t | confirm = kFALSE |
||
) |
Warning box in case of problems if confirm=kTRUE we ask for a yes/no answer from the user: if 'yes' is pressed, we return kTRUE, if 'no', kFALSE. by default, only a 'dismiss' button is shown, and this method always returns kTRUE.
Definition at line 1473 of file KVDataAnalysisLauncher.cpp.
|
private |
Definition at line 145 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 133 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 131 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 132 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 144 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 143 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 154 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 150 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 138 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 156 of file KVDataAnalysisLauncher.h.
|
private |
heigth of main window in pixels
Definition at line 170 of file KVDataAnalysisLauncher.h.
|
private |
width of main window in pixels
Definition at line 169 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 146 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 153 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 152 of file KVDataAnalysisLauncher.h.
|
private |
Declaration des boutons de la fenetre principale.
Definition at line 120 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 142 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 135 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 140 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 128 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 129 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 136 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 134 of file KVDataAnalysisLauncher.h.
|
private |
number of names in list
Definition at line 122 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 155 of file KVDataAnalysisLauncher.h.
|
private |
used by Get/SetResource
Definition at line 121 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 139 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 137 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 148 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 147 of file KVDataAnalysisLauncher.h.
|
private |
list of user classes present in working directory
Definition at line 159 of file KVDataAnalysisLauncher.h.
|
private |
Definition at line 149 of file KVDataAnalysisLauncher.h.
